10-Piece AlTiN-Coated Multi-Cut Carbide Burr Set for Metalworking in Aluminum Case
| Place of Origin | CHINA |
|---|---|
| Brand Name | CABURTECH |
| Certification | ISO9001-2008 |
| Model Number | Carbide Burr Set |
| Minimum Order Quantity | 100PCS/MODEL |
| Price | 1-80USD |
| Packaging Details | Standard Export Carton |
| Delivery Time | 15-30DAYS |
| Payment Terms | L/C,T/T,Western Union |
| Supply Ability | 60000-70000PCS/MONTH |
Product Details
| Model | SB-3M DC/SA-3M IN/SA-3M SC/SC-3M DC/SF-5M AL/SF-5M DM/SF-5M DC/SG-5M DC/SG-5M SK/SL-4M AL | Cut Dia | 9.6/12.7mm |
|---|---|---|---|
| Cut Length | 19/25/28mm | Shank | 6mm |
| Overall | 64/70/73mm | Cut | DC/IN/SC/AL/DM/SK |
| Coating | AlTiN | Material | Tungsten Carbide |
| Grade | YG8 | Type | Silver Braze |
| Workpiece | Steel, Cast Iron, Aluminum, Stainless Steel | ||
| Highlight | AlTiN-Coated Carbide Burr Set,Multi-Cut Rotary Burr Set,10-Piece Tungsten Carbide Burrs |
||
Product Description
10-Piece AlTiN-Coated Carbide Burr Set in Aluminum Case Multi-Cut for Metalworking
This set includes ten AlTiN-coated carbide rotary burrs packaged in two blue 5‑piece cases for organized storage and easy access. It features multiple shapes including cylinder, end-cut cylinder, ball nose cylinder, radius tree, pointed tree, and taper with radius, with six tooth profiles: double cut, INOX cut, single cut, aluminum cut, diamond cut, and single coarse cut. Suitable for cutting, finishing, and deburring of stainless steel, carbon steel, aluminum alloys, hardened steel, and general metals.
| Technical Parameters | ||||||
| Model | Cut dia (D1) | Cut length (D2) | Shank (L1) | Overall (L2) | Type | Cut |
| SB-3M DC | 9.6 | 19 | 6 | 64 | Silver braze | Double |
| SA-3M IN | 9.6 | 19 | 6 | 64 | Silver braze | INOX |
| SA-3M SC | 9.6 | 19 | 6 | 64 | Silver braze | Single |
| SC-3M DC | 9.6 | 19 | 6 | 64 | Silver braze | Double |
| SF-5M AL | 12.7 | 25 | 6 | 70 | Silver braze | Aluminum |
| SF-5M DM | 12.7 | 25 | 6 | 70 | Silver braze | Diamond |
| SF-5M DC | 12.7 | 25 | 6 | 70 | Silver braze | Double |
| SG-5M DC | 12.7 | 25 | 6 | 70 | Silver braze | Double |
| SG-5M SK | 12.7 | 25 | 6 | 70 | Silver braze | Single Coarse |
| SL-4M AL | 12.7 | 28 | 6 | 73 | Silver braze | Aluminum |
| Care Selections-carbide grades | Cobalt(%) | Hardness(HRA) | T.R.S(N/mm2) | |
| Carbide Grades | YG7 | 7 | 90.5 | 3000 |
| YG8 | 8 | 89.5 | 3400 | |
| YG6X | 6 | 91.7 | 3400 | |
| YG10X | 10 | 90-91 | 3000 | |
| Care Selections-Coatings | Color | Thickness(μm) | Hardness(Hmv) | |
| Coatings | AlTiN | Grey | 1-5 | 3000-3500 |
| TiN | Gold | 8-15 | 3200 | |
| Nanoblue | Blue | 8-15 | 3500 | |
| Gilt | Rainbow | 0.2-0.5 | 7000-8000 | |
The AlTiN coating enhances surface hardness and heat resistance, reducing wear during continuous use and extending tool life. The double cut balances efficiency with surface smoothness. The INOX cut reduces adhesion on stainless steel. The single cut is suitable for general trimming. The aluminum cut prevents clogging on soft metals. The diamond cut provides stable cutting on high-hardness materials. The single coarse cut allows rapid material removal. All tools are made from wear-resistant carbide, delivering stable performance during continuous operation.
The blue cases offer convenient organization and portability. Compatible with standard electric and pneumatic tools, the set is easy to operate and maintain. Widely used in machining, mold finishing, post-weld processing, and routine equipment maintenance, this is a versatile and reliable coated rotary burr kit.
Caburtech offers a wide selection of carbide burr shapes in Single and Double Cut styles, including Cylinder, Round nose cylinder, Ball, Oval, Tree, Flame, Cone, Countersink and Inverted Cone. Each shape is designed for grinding, deburring, chamfering, and finishing on steels under 60 HRC, stainless steels, cast iron and etc.
FAQ
1.How to Use:
This product belongs to the commonly used alloy consumables, and is designed to be used with high-speed electric grinders or pneumatic tools.
2.OEM:
We offer OEM services to cater to specific customer requirements.
3.MOQ:
The usual minimum order quantity is 100 pcs per model.
However, this can be adjusted based on your specific requirements. Please consult your sales representative for further details.
4.Lead Time:
The lead time for regular orders is approximately one month, excluding samples.
5.Port:
Shanghai/ Guangzhou/ Shenzhen/ Ningbo/ Yiwu/ Chengdu.
